Un-Armored Instrumentation Cables Collective Screen Multi-core 500V to BS EN 50288-7
APPLICATION
It works as signal carrier for Instrumentation equipments. Recommended to be used in indoor installation, on racks, in conduits, in dry and wet locations.
STANDARS & APPROVALS
BS EN 50288-7 Design guidelines of cable construction
BS EN 50290-2 Series Insulation and sheathing materials
IEC 60332-1-2 Flame retardant
IEC 60332-3-24 or 22 Flame retardant
IEC 60331 Fire resistant
on request
IEC-60754-1/...-2 Halogen free properties
IEC-61034-1/2 Smoke emission properties
DESIGN & CONSTRUCTION
1 CONDUCTOR
Cu - Annealed copper wires according to IEC 60288 Class 1 solid, Class 2 stranded (B), or Class 5 flexible conductors, available on demand.
Tinned copper conductors are available on demand 0.5, 0.75, 1.0, 1.5, 2.5 mm2, up to 50 cores.
2 INSULATION
XLPE - PE/XLPE/PVC/HFFR available on demand
Thickness - Min. 44 mm for 1.5 mm2 and below; Min. 0.53 mm for 2.5 mm2
3 SCREEN - OVERALL (OS)
Aluminium/polyester tape in electrical contact with tinned annealed drain wire
Or Copper/polyester tape in electrical contact with copper annealed drain wire
Or Copper wire braid
4 OUTER SHEATH
PE, PVC or LSZH (LSOH)
Hydrocarbon resistant option available on demand.
